Features of the single-action hydraulic drawing press

1. The single-action hydraulic drawing press process materials by drawing, bending, flanging, and blanking.

2. The steel welded structure of the deep drawing press has high rigidity, stable performance, high precision, and good resistance to eccentric loads.

3. With multiple working settings and forming technologies, this sheet metal pressing machine can meet the needs of a number of different customers and applications.

4. Optional devices for our metal forming machienry include a movable workign table, rapid mold changing device, hydraulic stamping part discharging device, and photoelectric protection unit.

Technical pa rameters of the single-action hydraulic drawing press

Item/Model		Unit	YJ27D-250	YJ27D-315	YJ27E-315Q	YJ27E-400	YJ27E-400Q
Nominal Force		kN	2500	3150	3150	4000	4000
Cushion Force		kN	1000	1250	1250	1600	1500
Pressure of Hydraulic System		Mpa	~25	~25	~25	~25	~25
Daylight		mm	1000	1200	1200	14 00	18 00
Strokes of Slide		mm	650	700	900	800	1400
Cushion Stroke		mm	250	250	300	300	400
Size of Table(L-R x F-B)		mm	1600x1200	1500x1400	2 200x1600	2300x1500	2800x1800
Bottom Size of Slide(L-R x F-B)		mm	1050x600	1050x600	1650x1050	1650x900	2250x1350
Speed of Slide	Idle	mm/s	150	150	200	250	450
	Pressing	mm/s	25-8	25-10	25-10	25-10	50-25
Speed of Cushion Knockout		mm/s	50	80	100	100	150
Moving Table Type			——	——		——
Height Between Table and Floor		mm	650	700	500	700	650
Main Motor Power		kW	22	37	37	44	100

Item/Model		Unit	YJ27E-630	YJ27E-630Q	YJ27E-630Y	YJ27E-800Q	YJ27E-800Y
Nominal Force		kN	6300	6300	6300	8000	8000
Cushion Force		kN	2500	2500	2000	3150	3150
Pressure of Hydraulic System		Mpa	~25	~25	~25	~25	~25
Daylight		mm	1600	1800	1800	1600	1800
Strokes of Slide		mm	1000	1400	1000	1250	1200
Cushion Stroke		mm	300	400	300	400	350
Size of Table(L-R x F-B)		mm	2300X2000	2800X1800	5000X2500	3200X2200	1500X1400
Bottom Size of Slide(L-R x F-B)		mm	1650X1350	2250X1350	4500X1950	2250X1350	1050X600
Speed of Slide	Idle	mm/s	250	450	300	400	400
	Pressing	mm/s	25-10	50-25	25-10	24-10	50-20
Speed of Cushion Knockout		mm/s	80	150	80	75	100
Moving Table Type			——			——
Height Between Table and Floor		mm	650	650	650	700	600
Main Motor Power		kW	90	180	90	198	322

Item/Model		Unit	YJ27E-1000	YJ27E-1000Q	YJ27E-2000Q	YJ27E-2500Q
Nominal Force		kN	10000	10000	20000	25000
Cushion Force		kN	2000	4000	6300	8000
Pressure of Hydraulic System		Mpa	~25	~25	~25	~25
Daylight		mm	1350	1800	2000	2200
Strokes of Slide		mm	900	1400	1400	1500
Cushion Stroke		mm	350	400	400	400
Size of Table(L-R x F-B)		mm	2200x1600	2000x1500	4000x2500	3200x2200
Bottom Size of Slide(L-R x F-B)		mm	1650x1050	1350x1050	3450x1950	2250x1350
Speed of Slide	Idle	mm/s	250	400	300	400
	Pressing	mm/s	25-15	24-10	25-10	20-8
Speed of Cushion Knockout		mm/s	80	100	100	120
Moving Table Type			——
Height Between Table and Floor		mm	600	600	650	750
Main Motor Power		kW	130	270	190	260
